5HP

Sailing of Boat with Small Outboard Motor 4 Stroke 5 HP Air Cooled System Live Video By Flyer



 Boats: 13ft Aluminium Boat

9.8ft inflatable Boat
Motor: (BUY IT)
Main Specification
Model:150
L×W×H(not including crank-shaft output terminal)(mm):307×295×240
Dry Weight(kg):13KG
Engine Type:single cylinder horizontal,4 stroke,5.0 HP,(OHV),forced air.
Displacement(ml):149
Bore × Stroke(mm):65 × 45
Compression ratio: 8.3:1
Recommended Using Power: 2.5kw, 3600r/min
Maximum Torque:9.0N·m,2500r/min
Fuel capacity(L):0.75
Oil capacity(L):0.4
Lubricating Oil brand: SAE 10W-30
Cooling System:Forced air
Ignition System:capacitance discharge type
PTO Shaft Rotation:vertical shaft output
Data Adjustment
Spark plug clearance:0.7 - 0.8mm
Carburetor idle speed:1900±100r/min
Valve clearance(cold engine):
intake —0.15±0.02mm
exhaust—0.20±0.02mm

You can see the fish flying around boat. It is a beauty view.
US CUKUSIN is a US brand to design and create outboard motor and boats that the manufacture is in Asia.
In CUKUSIN.COM, welcome agent.
